Supermicro 1U WIO SYS-112B-WR SuperServer
A future-proof foundation for AI inference, networking, and cloud workloads. The Supermicro SYS-112B-WR pairs a single Intel Xeon 6 processor (up to 86 cores) with up to 2TB of DDR5 memory and 10 hot-swap NVMe/SAS/SATA bays — unmatched I/O configurability in a compact, cost-efficient 1U footprint.
Product Overview
The Supermicro SuperServer SYS-112B-WR is a 1U Ultra-Performance Wide I/O (WIO) server engineered for maximum flexibility and efficiency in demanding enterprise environments, supporting up to 10 hot-swap 2.5" NVMe/SAS/SATA drive bays and 3 PCIe 5.0 expansion slots. At its core is a single Intel Xeon 6 processor with up to 86 P-cores/172 threads and 336MB cache — or 144 E-cores for efficiency-focused tasks — handling up to 350W TDP. Paired with 8 DIMM slots supporting up to 2TB of 6400MT/s ECC DDR5 RDIMM memory, it delivers fast data processing for databases, web caching, CDN, and video streaming. Storage flexibility includes native support for up to 8 PCIe 5.0 x4 NVMe drives plus 2 M.2 PCIe 5.0 slots for RAID-configurable boot volumes (VROC-enabled), with optional controllers like the AOC-S3908L-H8iR for seamless RAID integration. Networking is handled via dual 1GbE RJ45 LAN ports and a dedicated BMC IPMI port, while onboard TPM 2.0, Silicon Root of Trust, secure boot, and runtime protections meet NIST 800-193 compliance for security-sensitive AI and cloud deployments.
Key Specifications
- Brand
- SuperMicro
- Condition
- New
- Category
- SuperMicro X14 Servers
- Stock
- 10 units
- Processor
- Single Socket E2 (LGA-4710); Intel Xeon 6700/6500 series with P-cores or 6700 series with E-cores
- Core Count
- P-cores: up to 86C/172T, up to 336MB Cache; E-cores: up to 144C/144T, up to 108MB Cache
