Supermicro 1U Hyper SYS-122H-TN SuperServer
Dual-socket density, without the footprint. The Supermicro SYS-122H-TN packs dual Intel Xeon 6700/6500 processors, up to 8TB of DDR5 memory, and 12 hot-swap NVMe/SAS/SATA bays into a single 1U chassis — built for virtualization, HPC, and cloud infrastructure that demands maximum density.
Product Overview
The Supermicro SuperServer SYS-122H-TN is a high-efficiency 1U rackmount server optimized for virtualization, software-defined storage, HPC, cloud computing, and enterprise applications. Powered by the X14DBM-SP motherboard and dual Intel Xeon 6700/6500 Series P-core (up to 86C/172T) or 6700 Series E-core (up to 144C/144T) processors, it supports both air and liquid cooling. Featuring 32 DDR5 DIMM slots supporting up to 8TB of memory, storage options include up to 12 hot-swap 2.5" NVMe/SAS/SATA bays and dual M.2 PCIe 5.0 NVMe slots with optional RAID support. Expansion includes 3 PCIe 5.0 x16 slots plus 1 AIOM (OCP 3.0) slot, supporting up to 1 double-width or 3 single-width GPUs. Redundant power supplies, up to eight 40mm counter-rotating fans, and dual air shrouds ensure reliable operation, with IPMI 2.0, TPM 2.0, signed firmware, and Secure Boot for security and manageability.
Key Specifications
- Brand
- SuperMicro
- Condition
- New
- Category
- SuperMicro X14 Servers
- Stock
- 10 units
- Motherboard
- X14DBM-SP
- Processor
- Dual Intel Xeon 6700/6500 Series P-core (up to 86C/172T per CPU) or 6700 Series E-core (up to 144C/144T per CPU)
